Logging And Perforating Instruments

Hunting’s perforating gamma ray tools provide a rugged and reliable means of stratigraphic correlation depth control for completion operations.

The High Side Indicator tool (HSI) is used to report the relative bearing and inclination of the downhole tool string in the wellbore during oriented perforating applications.

Hunting’s DC-MOT (Magnetic Orienting Perforating Tool) positions zero phased perforating guns for control line avoidance.

Hunting’s Gamma Temperature/Pressure tools are a rugged and reliable means of correlation depth control for completion operations

Hunting’s Perforating Casing Collar Locators (CCL) are an extremely rugged and proven tool, designed to correlate depth to a base log, such as a gamma ray (GR)/CCL.

Hunting’s Digital Free Point Tool accurately determines the stuck point in pipe, tubing, or a casing string.

Titan's Motorized Free Point Tool accurately determines the stuck point in pipe, tubing or a casing string

KnockOut® Charges provide flow between two strings of tubing, pipe, or casing, or combination of.

The SPECTRA® family of jet cutters are engineered and manufactured at Hunting’s world-class Energetics facility

The SPECTRA® Tubing Cutter Detonator is very easy, and user friendly to install

The Noise Spectrum Tool is designed to measure downhole noise in the frequency range 100Hz to 12.7kHz.

Measuring casing wall thickness through an array of miniature sensors

A mechanical tool for well diameter measurement mainly composed of measuring fingers, driver rod and inductive sensors.

Hunting's standard single transmitter Cement Bond Log (CBL) tool accurately determines casing bond by measuring the amplitude of the first arrival at the 3ft receiver.

Titan’s industry leading High Definition Radial Incremented Bond (HD-RIB) tools.

Hunting’s family of CBL tools come in a range of sizes to accommodate casing sizes ranging from 2-3/8 in. (60 mm) to 9-5/8 in. (244.48 mm). The tools can be configured to several timing schemes for different logging systems.

The Radial Cement Bonding Tool (RBT) is a new type acoustic logging tool, consisting of acoustic part and electronics.

Divides casing, cement annulus and formation into six segments acquiring full wave train and analyzing cement bond between the formation and cement annulus

Hunting’s Logging Gamma Ray tools, built using shock mounting and vibration protection technology, offer operators a wide range of dependable service options and flexibility.

Making a depth correlation between the casing collars, and the open hole log of the well.

The FDR provides a reliable and comparatively safe means to measure wellbore fluid density

The caged springbow fullbore flowmeter (CSFM) is run at the bottom of the production logging tool (PLT) string.

The jeweled bearing flowmeter (IFJM) employs jewels for the support of the spinner pivot to reduce threshold displacement and improve sensitivity

The inline spinner flowmeter is a spinner flowmeter which provides an electrical feed-through.

A non-radioactive fluid-density measurement tool, measuring the density of a fluid sample as it flows through the tool

Measures the gas void fraction in the wellbore around the tool

Using a capacitance sensor for measuring water hold-up in fluid and a fast-response platinum sensor for measuring temperature

The Resistance Downhole Temperature Tool (RDT13) measures fluid temperature, providing information for fluid property analysis.

Runs centralised in the production logging toolstring

The Gamma Ray Tool (GRT) measures the natural gamma rays generated from the formation that surrounds the wellbore.

The CCT-CCL Tension Tool determines the tool depth by measuring the number of casing collars

An electric motor powered tractor system consisting of a surface control panel and downhole tools

The Tractor Control Panel functions as the interface panel between surface system and downhole tractor tool/tractor control cartridge. It also supplies DC power for other tools.

Records and displays the logging time, depth, line speed and tension in real time

An intelligent bridge between the tool bus and surface system collecting data from the tools

A simple ball adapter with a limited movement angle to enhance tool flexibility

An auxiliary tool for centering toolstring to be connected in vertical, deviated or horizontal well
