EQUAfrac® Precision
EQUAfrac Precision combines the best features of EQUAfrac and EQUAfrac Limited Shaped Charges.
This hybrid product offers more consistent hole size than the original EQUAfrac line, while still offering optimal penetration, and minimal debris. Perfect for horizontal completions while maintaining super consistency for applications requiring more than limited penetration.
Product variants
Specifications
- Model No
- EFP-312-19-372T
- Outside diameter
- 3-1/8 inch [79mm]
- Type
- EFP
- Target Type
- 5.5in 20# P110
- Explosive Type
- RDX
- Weight
- 19g
- Shot Density (SPF) [SPM]
- 6 [20] | 60°
- Hole Size
- 0.41 inches [10.41mm]
- Decentralized Entry Hole Variation
- 2.6%
- Penetration
- 21 inches [52.34cm]
- Model No
- EFP-312-19-372T
- Outside diameter
- 3-1/8 inch [79mm]
- Type
- EFP
- Target Type
- 5.5in 23# P110
- Explosive Type
- RDX
- Weight
- 19g
- Shot Density (SPF) [SPM]
- 6 [20] | 60°
- Hole Size
- 0.40 inches [10.16mm]
- Decentralized Entry Hole Variation
- 2.3%
- Penetration
- 21 inches [52.34cm]
- Model No
- EFP-312-19-372T
- Outside diameter
- 3-1/8 inch [79mm]
- Type
- EFP
- Target Type
- 4.5in 15# P110
- Explosive Type
- RDX
- Weight
- 19g
- Shot Density (SPF) [SPM]
- 6 [20] | 60°
- Hole Size
- 0.39 inches [9.90mm]
- Decentralized Entry Hole Variation
- 2.6%
- Penetration
- 21 inches [52.34cm]
- Model No
- EFP-312-19-372T
- Outside diameter
- 3-1/8 inch [79mm]
- Type
- EFP
- Target Type
- 4.5in 13.5# P110
- Explosive Type
- RDX
- Weight
- 19g
- Shot Density (SPF) [SPM]
- 6 [20] | 60°
- Hole Size
- 0.39 inches [9.90mm]
- Decentralized Entry Hole Variation
- 2.9%
- Penetration
- 21 inches [52.34cm]
- Model No
- EFP-312-19-371T
- Outside diameter
- 3-1/8 inch [79mm]
- Type
- EFP
- Target Type
- 5.5in 20# P110
- Explosive Type
- RDX
- Weight
- 19g
- Shot Density (SPF) [SPM]
- 6 [20] | 60°
- Hole Size
- 0.35 inches [8.89mm]
- Decentralized Entry Hole Variation
- 3.7%
- Penetration
- 21 inches [52.34cm]
- Model No
- EFP-312-19-371T
- Outside diameter
- 3-1/8 inch [79mm]
- Type
- EFP
- Target Type
- 5.5in 23# P110
- Explosive Type
- RDX
- Weight
- 19g
- Shot Density (SPF) [SPM]
- 6 [20] | 60°
- Hole Size
- 0.35 inches [8.89mm]
- Decentralized Entry Hole Variation
- 4%
- Penetration
- 21 inches [52.34cm]
- Model No
- EFP-312-21-371T
- Outside diameter
- 3-1/8 inch [79mm]
- Type
- EFP
- Target Type
- 4.5in 13.5# P110
- Explosive Type
- RDX
- Weight
- 21g
- Shot Density (SPF) [SPM]
- 6 [20] | 60°
- Hole Size
- 0.44 in [11.18 mm]
- Decentralized Entry Hole Variation
- 3.5%
- Penetration
- 21 inches [52.34cm]
- Model No
- EFP-312-21-371T
- Outside diameter
- 3-1/8 inch [79mm]
- Type
- EFP
- Target Type
- 5.5in 20# P110
- Explosive Type
- RDX
- Weight
- 21g
- Shot Density (SPF) [SPM]
- 6 [20] | 60°
- Hole Size
- 0.45 in [11.43 mm]
- Decentralized Entry Hole Variation
- 4%
- Penetration
- 21 inches [52.34cm]
- Model No
- EFP-312-21-371T
- Outside diameter
- 3-1/8 inch [79mm]
- Type
- EFP
- Target Type
- 5.5in 23# P110
- Explosive Type
- RDX
- Weight
- 21g
- Shot Density (SPF) [SPM]
- 6 [20] | 60°
- Hole Size
- 0.44 in [11.18 mm]
- Decentralized Entry Hole Variation
- 5%
- Penetration
- 21 inches [52.34cm]
| EFP-312-19-372T | EFP-312-19-372T | EFP-312-19-372T | EFP-312-19-372T | EFP-312-19-371T | EFP-312-19-371T | EFP-312-21-371T | EFP-312-21-371T | EFP-312-21-371T | |
|---|---|---|---|---|---|---|---|---|---|
| Outside diameter | 3-1/8 inch [79mm] | 3-1/8 inch [79mm] | 3-1/8 inch [79mm] | 3-1/8 inch [79mm] | 3-1/8 inch [79mm] | 3-1/8 inch [79mm] | 3-1/8 inch [79mm] | 3-1/8 inch [79mm] | 3-1/8 inch [79mm] |
| Type | EFP | EFP | EFP | EFP | EFP | EFP | EFP | EFP | EFP |
| Target Type | 5.5in 20# P110 | 5.5in 23# P110 | 4.5in 15# P110 | 4.5in 13.5# P110 | 5.5in 20# P110 | 5.5in 23# P110 | 4.5in 13.5# P110 | 5.5in 20# P110 | 5.5in 23# P110 |
| Explosive Type | RDX | RDX | RDX | RDX | RDX | RDX | RDX | RDX | RDX |
| Weight | 19g | 19g | 19g | 19g | 19g | 19g | 21g | 21g | 21g |
| Shot Density (SPF) [SPM] | 6 [20] | 60° | 6 [20] | 60° | 6 [20] | 60° | 6 [20] | 60° | 6 [20] | 60° | 6 [20] | 60° | 6 [20] | 60° | 6 [20] | 60° | 6 [20] | 60° |
| Hole Size | 0.41 inches [10.41mm] | 0.40 inches [10.16mm] | 0.39 inches [9.90mm] | 0.39 inches [9.90mm] | 0.35 inches [8.89mm] | 0.35 inches [8.89mm] | 0.44 in [11.18 mm] | 0.45 in [11.43 mm] | 0.44 in [11.18 mm] |
| Decentralized Entry Hole Variation | 2.6% | 2.3% | 2.6% | 2.9% | 3.7% | 4% | 3.5% | 4% | 5% |
| Penetration | 21 inches [52.34cm] | 21 inches [52.34cm] | 21 inches [52.34cm] | 21 inches [52.34cm] | 21 inches [52.34cm] | 21 inches [52.34cm] | 21 inches [52.34cm] | 21 inches [52.34cm] | 21 inches [52.34cm] |
